Specified Gear Oil
When replacing gear oil, use gear oil with the appropriate viscosity and grade as shown in the charts below. We highly recommend you use SAE 75W-90 gear oil (SAE 80W-90 for front differential oil, rear differential oil and transfer gear oil).
Manual Transmission Fluid for a Suzuki Vitara Use the fitment form at the top of the page to select your exact year and engine type for your Suzuki Vitara. Valvoline Syn High Mile - Full Synthetic High Mile with MaxLife Technology SAE 5W-30 Motor Oil, 5 Quart (Part No. Vitara manual transmission fluid change - YouTube I'm changing the transmission fluid on a 2004 Suzuki Forenza. The transmission is an automatic ZF 4HP16 Page 14/40. The engine and transmission are longitudinally mounted unlike most front-wheel drive based compact SUVs in its class. Engines are available with either a 5-speed manual or 5-speed automatic transmission. The Grand Vitara is available in both rear-wheel drive only models (for the Australian market) or with a 4-mode all-wheel drive system.
To check the gear oil level in any of the above locations, use the following procedure: 1) Park the vehicle on a level surface. Set parking brake and stop the engine. 2) Remove the oil filler plug (1). 3) Check the inside of the hole with your finger. If the oil level comes up to the bottom of the plug hole, the oil level is correct. Buy used Suzuki Grand Vitara 4WD ⏩ Check prices for Four Wheel Drive Suzuki Grand Vitara models for sale, find a dealership near you in the US and shop for your car with great deals and offers Suzuki Vitara Service Repair Manual PDF The Suzuki Grand Vitara is compact sport utility and off-road vehicle from Japanese automaker Suzuki.
Transmission/Extension case
Differential/Transfer case
2017 Vitara Manual Transmission Oil Typed
Manual transmission (1) Oil filler and level plug (2) Oil drain plug
Transfer case (1) Oil filler and level plug (2) Oil drain plug
Extension case (2WD) (1) Oil filler and level plug (2) Oil drain plug
Front differential (1) Oil filler and level plug (2) Oil drain plug
Rear differential (1) Oil filler and level plug (2) Oil drain plug
Gear Oil Level Check
The manual transmission, transfer gears, extension case and differentials (front and rear) are lubricated with gear oil. To check the gear oil level in any of the above locations, use the following procedure: 1) Park the vehicle on a level surface. Set parking brake and stop the engine. 2) Remove the oil filler plug (1). 3) Check the inside of the hole with your finger. If the oil level comes up to the bottom of the plug hole, the oil level is correct. If so, reinstall the plug. 4) If the oil level is low, add gear oil through the filler plug hole (1) until the oil level reaches the bottom of the filler hole, then reinstall the plug.
Gear Oil Replacement
To change the gear oil in the manual transmission, transfer case, extension case or differential(s), use the following procedure: 1) Remove the oil filler plug (1). 2) Remove the drain plug (2), drain the oil and reinstall the drain plug. 3) Pour new gear oil of the specified type through the filler hole until the oil level reaches the bottom of the filler hole. 4) Reinstall the filler plug.
WARNING: After driving the vehicle, gear oil temperature may be high enough to burn you. Wait until the oil filler plug is cool enough to touch with your bare hands before inspecting or replacing gear oil.
CAUTION: When tightening these plugs, apply sealing compound “SUZUKI Bond No. 1215” or equivalent to the plug threads to prevent oil leakage and tighten them to the specified torque shown below.
Tightening torque
